Aykom 4kW 300 Litre Screw Compressor with Dryer / Receiver
Description
ATV TD is a series of belt-driven screw compressors that includes an internal air tank and dryer. The Poly V belt-pulley drive system ensures power transmission at maximum performance, while the CE-certified air tank has a capacity of 530 liters, and the compressed air dryer features a dew point of 3°C as standard equipment. Businesses that require dry compressed air can confidently choose the appropriate compressor model from our ATV TD series to meet their compressed air needs. Capacity: 7 bar - 0.64 m3/min 10 bar - 0.49 m3/min 13 bar - 0.40 m3/min Air Dryer Model: TMP-HK 38 Motor Power: 4 kw/5.5hp Voltage/Phase: 400V/3PH Connections: 1/2" Dimensions (cms): 603L x 1611W x 1346H Note: photo 2 is not exact unit, this is a ATV 11 DK for reference. Enquire for more information specific to your requirements.
Specifications
-
Reservoir Capacity:300L
-
Key Feature Noun/Adjectiv:Screw
-
Rated Flow:0.58m3pm/20cfm
-
Rated Pressure:7-13bar
-
Power Source:400V/3Ph
-
Power Rating kW:4
-
Power Rating hp:5.4
-
Inlet Size Type:2"
-
Outlet Size and Type:2"
-
Weight KG:225
