BA Pump And Sprayers 650L 3pt Linkage Sprayer 6m Proline Boom 50m H/Reel PA530 Pump
Description
The BA001-530FP is the BA Pumps & Sprayers 650 Litre Farm Pack 3-Point Linkage Sprayer. This is a heavy-duty, tractor-mounted agricultural implement designed for serious pasture maintenance, weed management, and cropping on medium-to-large blocks. Tank Properties: 650 Litre high-capacity, UV-stabilized translucent polyethylene tank featuring active built-in jet agitation to prevent chemical separation. Frame Design: Heavy-duty, hot-dipped galvanized steel chassis engineered for Category 1 and 2 three-point tractor linkages. High-Volume Pump: Equipped with a Bertolini PA530 positive displacement diaphragm pump driven by the tractor’s Power Take-Off (PTO) shaft. It delivers an immense 54 Litres per minute (LPM) open flow rate at up to 40 Bar (580 PSI) maximum pressure. 6-Meter Pro-Line Series Spray Boom: Features multi-section plumbing outfitted with TeeJet AIXR low-drift flat fan nozzles. Hose Reel: An integrated 50-meter heavy-duty MAXI-Reel manual spool paired with a high-impact professional spot spray gun. Pressure Regulator: A manual Bertolini master control valve setup (Sting 3-tap block) to adjust system pressure on the fly.
Specifications
-
Reservoir Capacity:650L
-
Key Feature Noun/Adjectiv:6M Boom and Hose Reel
-
Rated Flow:0.054m3pm
-
Rated Pressure:580PSI
-
Power Source:PTO
-
Material:Polyethylene (PE)
-
Weight KG:200
